Decorative Outdoor Lighting

Bemidji (DBS)

Bemidji (DBS)
Get a QuoteRequest a quote online View Catalog

Anchor Bolts

Anchor bolts conform to ASTM F1554 Grade-55 standards. Bolts have an “L” bend at one end and a minimum of 12” galvanized threads on the other end. Each bolt comes fashioned with two flat washers and two hexagonal nuts.

Base Style

Each pole assembly is fashioned with a Millerbernd Manufacturing Company Decorative High Base. The base is fabricated from the same material as the pole shaft and stands 43 inches tall. The pole shaft is slip fitted and welded to the base.

Shaft

The pole shaft conforms to ASTM A1011 Grade 50 carbon steel or ASTM A240 Grade 201L stainless steel standards and is formed with a constant linear taper.

Handhole

A reinforced doorway with cover, grounding lug, and hardware is provided with each pole assembly.

Arms

Bemidji arms are fabricated from 2” (2.38” O.D.) schedule 40 pipe and are circumferentially welded to a cast decorative cap. The Bemidji arm is slip fitted over the pole top and is held in place with set screws. The Bemidji arm is formed with a soft “S” curve and has a rise of 3 feet above the pole top.

Finish Options

Carbon steel poles are to be specified as hot-dip galvanized per ASTM A123 or finish painted with our standard Millerbond Wet Coat Finish. Multi-sided stainless steel poles are to be specified as frost (rust resistant stainless steel shot blast) finished or finish painted with our standard Millerbond Wet Coat Finish.

Hardware

All hardware and fasteners are supplied with each pole assembly. All structural fasteners are galvanized high-strength carbon steel or 18-8 stainless steel.

Tap to expand details below

  • Anchor Bolts

    Anchor Bolts

    Anchor bolts conform to ASTM F1554 Grade-55 standards. Bolts have an “L” bend at one end and a minimum of 12” galvanized threads on the other end. Each bolt comes fashioned with two flat washers and two hexagonal nuts.

  • Base Style

    Base Style

    Each pole assembly is fashioned with a Millerbernd Manufacturing Company Decorative High Base. The base is fabricated from the same material as the pole shaft and stands 43 inches tall. The pole shaft is slip fitted and welded to the base.

  • Shaft

    Shaft

    The pole shaft conforms to ASTM A1011 Grade 50 carbon steel or ASTM A240 Grade 201L stainless steel standards and is formed with a constant linear taper.

  • Handhole

    Handhole

    A reinforced doorway with cover, grounding lug, and hardware is provided with each pole assembly.

  • Arms

    Arms

    Bemidji arms are fabricated from 2” (2.38” O.D.) schedule 40 pipe and are circumferentially welded to a cast decorative cap. The Bemidji arm is slip fitted over the pole top and is held in place with set screws. The Bemidji arm is formed with a soft “S” curve and has a rise of 3 feet above the pole top.

  • Finish Options

    Finish Options

    Carbon steel poles are to be specified as hot-dip galvanized per ASTM A123 or finish painted with our standard Millerbond Wet Coat Finish. Multi-sided stainless steel poles are to be specified as frost (rust resistant stainless steel shot blast) finished or finish painted with our standard Millerbond Wet Coat Finish.

  • Hardware

    Hardware

    All hardware and fasteners are supplied with each pole assembly. All structural fasteners are galvanized high-strength carbon steel or 18-8 stainless steel.

Get a QuoteRequest a quote online View Catalog

Options & Detail

  • Cross Section Options
    Cross Section: Octagonal, 16S-Flute
  • Base Detail
    Base Detail

Specifications

Use horizontal scroll bar at bottom of each table to view all columns

Swipe to view all columns

Carbon Steel

PART # MOUNTING
HEIGHT
(FT)		 MAX ARM
LENGTH
(FT)		 WEIGHT
(LBS.)		 BASE O.D.
(IN)		 TOP O.D.
(IN)		 BOLT CIRCLE
+/- 0.5
(IN)		 BASE
SQUARE
(IN)		 MAX EPA
90 MPH		 MAX EPA
100 MPH		 MAX EPA
110 MPH		 MAX EPA
120 MPH		 MAX EPA
130 MPH		 MAX EPA
140 MPH		 MAX EPA
150 MPH
DBS-081-A-070-200 20 8 267 7 4 12 18.5 5.85 5.2 4.56 3.96 3.42 2.94 2.52
DBS-081-A-070-250 25 8 302 7 4 12 18.5 5.71 5.04 4.4 3.8 3.26 2.79 2.39
DBS-081-A-075-300 30 8 344 7.5 4 12 18.5 5.6 4.92 4.26 3.67 3.14 2.68 2.28
dbs-081-a-075-350 35 8 363 7.5 4 12 18.5 5.5 4.81 4.15 3.56 3.04 2.58 2.19
dbs-081-a-075-400 40 8 401 7.5 4 12 18.5 5.41 4.71 4.06 3.47 2.95 2.5 1.21

Stainless Steel

PART # MOUNTING
HEIGHT
(FT)		 MAX ARM
LENGTH
(FT)		 WEIGHT
(LBS.)		 BASE O.D.
(IN)		 TOP O.D.
(IN)		 BOLT CIRCLE
+/- 0.5
(IN)		 BASE
SQUARE
(IN)		 MAX EPA
90 MPH		 MAX EPA
100 MPH		 MAX EPA
110 MPH		 MAX EPA
120 MPH		 MAX EPA
130 MPH		 MAX EPA
140 MPH		 MAX EPA
150 MPH
DBS-081-E-070-200 20 8 196 7 4 12 18.5 3.2 2.79 2.4 2.04 1.71 1.42 1.16
DBS-081-E-070-250 25 8 217 7 4 12 18.5 3.11 2.7 2.3 1.94 1.61 1.3 0.63
DBS-081-E-075-300 30 8 237 7.5 4 12 18.5 3.04 2.62 2.22 1.26
dbs-081-e-075-350 35 8 268 7.5 4 12 18.5 2.98 2.55 2.16 1.79 0.64
dbs-081-f-075-350 35 8 339 7.5 4 12 18.5 2.98 2.55 2.16 1.79 1.48 1.2 0.96
dbs-081-f-075-400 40 8 377 7.5 4 12 18.5 2.92 2.5 2.1 1.74 1.42 1.15
  1. Variations from above sizes are available. Consult factory for allowable weight and EPA ratings for custom sizes.
  2. Charts are for single arm configurations only. Consult factory for allowable weight and EPA ratings on twin arm arrangements.
  3. Charted weights include the base, pole shaft, and luminaire mounting arm.
